Reduce your chassis footprint, without compromising on hardware. The Jonsbo D41 Mesh Screen ATX PC Case has a precise structural layout that enables you to instal all the latest and greatest hardware, whilst only having a 35.4L volume. The sleek, smooth panels make this case effortlessly blend into any aesthetic, with an amazing 8” LCD screen integrated on the front panel to complete the look. Plus, there is extensive support for cooling components as well as ventilation integrated throughout the chassis. Stylish, cool performance from the Jonsbo D41.

JONSBO D41 MESH SCREEN ATX PC CASE AT A GLANCE:

ATX PC case with integrated 8” LCD screen
Supports up to ATX motherboards and 400mm GPUs
Four mounting options for power supply
High density ventilation on top panel for superior exhaust performance
Tempered glass side panel and steel construction
Extensive support for fans and AIO radiators

ATX STYLE

The Jonsbo Screen D41 PC Case balances compact sizing and sleek style. This chassis has a ATX form factor, with an overall small footprint yet a spacious 35.4L volume. The steel panels are smooth with distinct lines for a crisp and clean finish. Available in two colours, this model is classic black. Plus, the tempered glass side panel offers an amazing view into the chassis, perfect for showcasing all your high-end hardware.

LCD SCREEN

The stand-out feature of the Jonsbo D41 Mesh Screen is the 8” LCD screen integrated on the front panel. Occupying a third of the panel, this display has a 1280 x 800 resolution, 60Hz refresh rate, and 16:10 aspect ratio. This screen can be used to display hardware statuses or even your favourite animated wallpaper!* With 16.7 million colours at its disposal, all images are crisp and vibrant. The screen, itself, is protected by a 1.1mm thick scratch resistant glass, with a 6 Mohs hardness rating. Additionally, on the side are controls to adjust brightness, as well as a power button.

What’s more, it can be removed from the case and used a second monitor with your gaming PC. With both Mini HDMI and USB-C connectivity, you have ample means to integrate this screen into your system. Should you remove the screen from your case, there is a replacement mesh panel included within the scope of delivery, designed to fill the gap the LCD screen leaves.

*No software is pre-installed. Jonsbo recommends Wallpaper Engine and AIDA64.

OUTSTANDING AIRFLOW

There is extensive cooling support throughout the Jonsbo D41 Mesh Screen. To start with, the top and front panel have 92% coverage of high-density mesh, facilitating superior exhaust performance. What’s more, much of the internal structure also sports ventilation, to enhance airflow throughout the case.

You can instal an array of fans and AIO radiators in the Jonsbo D41 Mesh Screen. The top panel can accommodate either three 120mm or 140mm fans or an AIO radiator up to 360mm. This is also true of the bottom panel. Both the front and rear panels can hold a singular 120mm fan. Plus, there is clearance for a CPU cooler up to 168mm tall. Overall, this allows for a versatile thermal solution, whether you opt for air- or water-cooling.

POWER AND GRAPHICS

The Jonsbo D41 utilises a compact style yet can accommodate motherboards up to the ATX form factor. There are seven expansion slots to support PCIe devices, such as graphics cards. Naturally, with its small footprint, there are a few limitations on what hardware can be installed. However, thanks to the four power supply mounting options, you have incredible flexibility in terms of the graphics card and PSU.

The power supply is mounted onto the front panel and can orientated with the air intake facing into the chamber or into the frame. There is subtle ventilation down the side of the front panel to enable air intake, should you opt for the latter. On top of this, there are four mounting positions available, which will determine what size GPU and PSU you can use in this build.

Level One: This is the topmost mounting positing. With a 140mm to 160mm long PSU, you can instal a graphics card up to 400mm long. Should you need a larger 180mm power supply, then the graphics card size will range between 342mm and 360mm. As the PSU is near the top of the chassis, you are limited to a 280mm AIO or two fans upon the ceiling.
Level Two: This places PSU 15mm lower than the top position. Putting a PSU measuring 140mm in this slot enables you to install a GPU up to 400mm long. With a 150mm to 180mm long power supply, graphics card clearance goes to 342mm to 360mm. Plus, you can fit the full three 120mm fans on the top panel.
Level Three: This mount is 21.6mm lower than level two. With a 140mm to 160mm power supply, you can instal a GPU between 342mm and 360mm. Should you need a larger 180mm power supply, then the GPU clearance reduces to 335mm. At this height, there is also clearance for 360mm AIO radiators on the top panel.
Level Four: The lowest of the mounts, this is 15mm below level three. Here you can mount a PSU between 140mm and 160mm with a GPU up to 360mm long. Opting for a 180mm PSU allows for graphics cards up to 335mm long. There is also ample space for a 360mm AIO radiator on the top panel.

STORAGE AND I/O

Providing you with a flexible storage solution, the Jonsbo D41 Mesh Screen has two storage modes. The first utilises a drive case on the bottom panel, which can hold two 3.5” HDDs and a single 2.5” SSD, in conjunction with the two SSD tray mounts on the motherboard backplate. Alternatively, you can omit the drive cage and install a single 3.5” HDD directly onto the bottom panel. The two SSD trays can also be used with this configuration. Whichever mode you use, this case has support for both speed and capacity. Hardware is incredibly easy to instal, as well, thanks to the toolless design this case sports. It disassembles into nine sections, creating ease of access to every part of the chassis.

The Jonsbo D41 sports great connectivity. Placed towards the lower edge of the front panel, the I/O features a USB 3.0 and USB-C port, as well as an audio and mic jack. Plus, there is a seamless power button placed above them, to keep the design sleek and fresh.

JONSBO D41 ATX PC CASE SPECIFICATIONS:

Brand	Jonsbo
Model	D41 Mesh Screen PC Case
Colour	Black
Form Factor	ATX
Dimensions	205mm x 407mm x 452mm W x H x D
Volume	35.4L
Materials	0.6mm steel 1.7mm steel Tempered glass
Motherboard Support	Micro-ATX ATX
Expansion Slots	7
GPU Support	330mm – 400mm GPU size depends on PSU size and placement
PSU Support	ATM power supply Four mounting options
Storage	2 x 3.5” HDD 3 x 2.5” SSD bays on motherboard backplate
Fan Support	Top: 3 x 120mm or 2 x 140mm fans Bottom: 3 x 120mm or 2 x 140mm fans Front: 1 x 120mm fan Rear: 1 x 120mm
Radiator Support	Top: 1 x 360 / 280 / 240 AIO Bottom: 1 x 360 / 240 AIO Rear: 1 x 120 AIO
CPU Cooler	Up to 168mm tall
I/O Panel	1 x USB 3.2 Gen 2 Type-C 1 x USB 3.0 1 x Audio and mic
Weight	Net: 6.78kg

Jonsbo D41 Mesh Screen Black ATX Case
